DC AudioCustom Built: Estimated lead time of 5-15 Business days.
SKU: DC Audio Level 5 Elite 12 M5 3500w Subwoofer
Categories : (Brand) DC Audio
In Stock
$1,054.99 $1,349.99
Save $295.00

Here it is, the m5 version of the Lv5 subwoofer. Built for ground pounding and taking abuse in or out of the competition lanes.

When we went to the drawing board with this one, we were looking to make improvements in cooling, motor force and soft parts, With the surround / cone, solid pole, machined cooling vents, 10” Spiders and a 3.5" coil we accomplished all of those things and then some.

The end result is a sub that works great in the SPL lanes as well as Pounding out the LOWS!!

Key Features

  • Extremely strong kraft pulp fiber reinforced cone
  • Wide Long Throw foam surround
  • Dome polypropylene dust cover with White DC logo
  • 10” OD Spaced Spiders
  • Extra heavy duty sewn tinsel lead wire
  • Cast DC Series aluminum black frame
  • FEA analyzed and optimized motor assembly – Fully CNC machined
  • Rubber mounting gasket
  • Rubber Motor Boot
  • 8 Awg OFC Direct Leads
  • 3.5” 8 Layer Hi-temp Aluminum voice coil wound on a Black Anodized Aluminum voice coil former with high current input strips.
  • Power Handling : 3500 Watts RMS 7000 Watts Peak

 T/S Parameters

12" 15" 18"
Mounting Depth 10.5" 11.75" 12.75"
Mounting Hole Diameter 11.15" 14.25" 16.90"
Outside Driver Diameter 12.5" 15.7" 18.5"
VC Diameter 3.5" 3.5" 3.5"
Displacement .19 ft .23 ft .26ft
Power Handling rms/peak 3500/7000 3500/7000 3500/7000
Ohm Options d.7/d1/d2/d4 d.7/d1/d2/d4 d.7/d1/d2/d4
Sd 494 cm 791. cm 1159 cm
Vas 18.19 L 48.98 L N/A L
Cms 61.22 um/n 55.12 um/n N/A Mm/n
Mms 442.01 g 487.2 g N/A g
Fs 30.59 Hz 30.7 Hz N/A Hz
Bl 29.21 N/A 31.38N/A 31.38 N/A
Re 4.01 Ohm 3.26 Ohm 3.26 Ohm
Le 4.29 mH 1.86 mH N/A mH
Qms 8.56 5.59
 N/A
Qes 0.399 0.310
 N/A
Qts 0.381 0.300
 N/A
Xmax 32mm 32mm 32mm
Ref SPL @1 watt 82.89 db 89.4 db 90.4 db
Suggest Sealed Box N/A N/A ft 3.5 ft
Suggested Ported Box 1.50 ft 3.25 ft 5.5 ft

Add to wishlist
Add to compare
Payment Options

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

Here it is, the m5 version of the Lv5 subwoofer. Built for ground pounding and taking abuse in or out of the competition lanes.

When we went to the drawing board with this one, we were looking to make improvements in cooling, motor force and soft parts, With the surround / cone, solid pole, machined cooling vents, 10” Spiders and a 3.5" coil we accomplished all of those things and then some.

The end result is a sub that works great in the SPL lanes as well as Pounding out the LOWS!!

Key Features

  • Extremely strong kraft pulp fiber reinforced cone
  • Wide Long Throw foam surround
  • Dome polypropylene dust cover with White DC logo
  • 10” OD Spaced Spiders
  • Extra heavy duty sewn tinsel lead wire
  • Cast DC Series aluminum black frame
  • FEA analyzed and optimized motor assembly – Fully CNC machined
  • Rubber mounting gasket
  • Rubber Motor Boot
  • 8 Awg OFC Direct Leads
  • 3.5” 8 Layer Hi-temp Aluminum voice coil wound on a Black Anodized Aluminum voice coil former with high current input strips.
  • Power Handling : 3500 Watts RMS 7000 Watts Peak

 T/S Parameters

12" 15" 18"
Mounting Depth 10.5" 11.75" 12.75"
Mounting Hole Diameter 11.15" 14.25" 16.90"
Outside Driver Diameter 12.5" 15.7" 18.5"
VC Diameter 3.5" 3.5" 3.5"
Displacement .19 ft .23 ft .26ft
Power Handling rms/peak 3500/7000 3500/7000 3500/7000
Ohm Options d.7/d1/d2/d4 d.7/d1/d2/d4 d.7/d1/d2/d4
Sd 494 cm 791. cm 1159 cm
Vas 18.19 L 48.98 L N/A L
Cms 61.22 um/n 55.12 um/n N/A Mm/n
Mms 442.01 g 487.2 g N/A g
Fs 30.59 Hz 30.7 Hz N/A Hz
Bl 29.21 N/A 31.38N/A 31.38 N/A
Re 4.01 Ohm 3.26 Ohm 3.26 Ohm
Le 4.29 mH 1.86 mH N/A mH
Qms 8.56 5.59
 N/A
Qes 0.399 0.310
 N/A
Qts 0.381 0.300
 N/A
Xmax 32mm 32mm 32mm
Ref SPL @1 watt 82.89 db 89.4 db 90.4 db
Suggest Sealed Box N/A N/A ft 3.5 ft
Suggested Ported Box 1.50 ft 3.25 ft 5.5 ft
