DC Audio Level 5 Elite 18 M5 3500w Subwoofer

DC Audio Level 5 Elite 18 M5 3500w Subwoofer

DC AudioCustom Built: Estimated lead time of 5-15 Business days.

SKU: DC Audio Level 5 Elite 18 M5 3500w Subwoofer

In Stock

$1,144.99 $1,449.99

Save $305.00

Here it is, the m5 version of the Lv5 subwoofer. Built for ground pounding and taking abuse in or out of the competition lanes.

When we went to the drawing board with this one, we were looking to make improvements in cooling, motor force and soft parts, With the surround / cone, solid pole, machined cooling vents, 10” Spiders and a 3.5" coil we accomplished all of those things and then some.

The end result is a sub that works great in the SPL lanes as well as Pounding out the LOWS!!

Key Features

Extremely strong kraft pulp fiber reinforced cone
Wide Long Throw foam surround
Dome polypropylene dust cover with White DC logo
10” OD Spaced Spiders
Extra heavy duty sewn tinsel lead wire
Cast DC Series aluminum black frame
FEA analyzed and optimized motor assembly – Fully CNC machined
Rubber mounting gasket
Rubber Motor Boot
8 Awg OFC Direct Leads
3.5” 8 Layer Hi-temp Aluminum voice coil wound on a Black Anodized Aluminum voice coil former with high current input strips.
Power Handling : 3500 Watts RMS 7000 Watts Peak

T/S Parameters

	12"	15"	18"
Mounting Depth	10.5"	11.75"	12.75"
Mounting Hole Diameter	11.15"	14.25"	16.90"
Outside Driver Diameter	12.5"	15.7"	18.5"
VC Diameter	3.5"	3.5"	3.5"
Displacement	.19 ft	.23 ft	.26ft
Power Handling rms/peak	3500/7000	3500/7000	3500/7000
Ohm Options	d.7/d1/d2/d4	d.7/d1/d2/d4	d.7/d1/d2/d4
Sd	494 cm	791. cm	1159 cm
Vas	18.19 L	48.98 L	N/A L
Cms	61.22 um/n	55.12 um/n	N/A Mm/n
Mms	442.01 g	487.2 g	N/A g
Fs	30.59 Hz	30.7 Hz	N/A Hz
Bl	29.21 N/A	31.38N/A	31.38 N/A
Re	4.01 Ohm	3.26 Ohm	3.26 Ohm
Le	4.29 mH	1.86 mH	N/A mH
Qms	8.56	5.59	N/A
Qes	0.399	0.310	N/A
Qts	0.381	0.300	N/A
Xmax	32mm	32mm	32mm
Ref SPL @1 watt	82.89 db	89.4 db	90.4 db
Suggest Sealed Box	N/A	N/A ft	3.5 ft
Suggested Ported Box	1.50 ft	3.25 ft	5.5 ft
