DC Audio XL Elite M4 15" 2200w Subwoofer

DC AudioCustom Built: Estimated lead time of 5-15 Business days.

SKU: DC Audio XL Elite M4 15" 2200w Subwoofer

In Stock

$869.99 $1,039.99

Save $170.00

The XL m4 ELITE is an Evolution of our #1 Selling XL Subwoofer line. We have redesigned the motor giving it a fresh new look, Added a pole vent and larger magnets, FEA optimized it and mated it with the DC Frame using 10 inch spiders.

The sub came from demand. XL style motor, 3 inch 8 layer coil, 10 inch spiders and the “famous for its performance and good looks” DC Frame in 15 and 18!!

Key Features

Extremely rigid non-pressed paper cone assembly
Multilayered polymer foam surround
Polypropylene dust cover with DC logo
Quad 10"OD Spiders
Dual Extra heavy duty interweaved tinsel lead wire
Cast Heavy Duty DC Aluminum black & Grind frame
FEA analyzed and optimized motor assembly – Fully CNC machined
Rubber mounting gasket
Rubber Motor Boot
8 Awg DC OFC Direct Leads
3" 8 Layer Flat Wound Hi-temp Aluminum Voice Coil
Power Handling: 2200 Watts RMS 4400 Watts Peak

	12"	15"	18"
Mounting Depth	9.75"	11"	12"
Mounting Hole Diameter	11.15"	14.25"	16.90"
Outside Driver Diameter	12.5"	15.7"	18.5"
VC Diameter	3.0"	3.0"	3.0"
Displacement	.19 ft	.23 ft	.26ft
Power Handling rms/peak	2200/4400	2200/4400	2200/4400
Ohm Options	d.7/d1/d2/d4	d.7/d1/d2/d4	d.7/d1/d2/d4
Sd	494 cm	791 cm	1159 cm
Vas	22.368 L	N/A L	129.16 L
Cms	0.076 Mm/n	N/A Mm/n	61.35 um/n
Mms	332.5 g	367.4 g	534.19 g
Fs	31.63 Hz	30.1 Hz	27.8 Hz
Bl	24.165 N/A	23.73 N/A	26.49 N/A
Re	4.169 Ohm	1.8 Ohm	4.66 Ohm
Le	5.539 mH	N/A mH	4.42 mH
Qms	6.204	6.31	8.27
Qes	0.4717	0.37	0.62
Qts	0.4384	0.35	0.577
Xmax	34mm	34mm	34mm
Ref SPL @1 watt	N/A	90.3 db	88.25 db
Suggest Sealed Box	1.0 ft	2.0 ft	3.5 ft
Suggested Ported Box	1.50 ft	3.25 ft	5.5 ft
