I Series 12 500RMS Subwoofer by Incriminator Audio®
The I Series Subwoofers from Incriminator Audio were designed with the entry level consumer in mind. Rated at a very conservative 500 watts RMS, the large voice coil and magnet structure of this line of drivers give entry level a new meaning. Other entry level subwoofers are designed with cosmetics in mind, hoping to prey on inexperienced users, but not the I Series. It was designed strictly with performance and functionality in mind. The consumers money isn’t wasted on flashy parts and useless lighting. Instead the I Series owner is getting a reliable, strong, solid subwoofer that is very loud and produces clean sounding tight bass that one would expect to hear from a much higher priced line of subwoofers. The I Series line of subwoofers is offered in 10”, and 12” models and all have the option of dual 2 or dual 4 ohm voice coils.
- 4 Spoke Black Stamped Steel Basket
- 2.5" 4 Layer Aluminum Voice Coil
- Double Black Progressive Spiders with Woven Tinsels
- Injected Pulp Matrix Fiber Reinforced Cone
- Dual Layer Surround
- 90 Oz Double Magnet Structure with Black Finish
- Nickel-Plated Push Terminals
- Wrap Around Rubber Gasket
- 500 Watt RMS Rated
- DVC 2 ohm or DVC 4 ohm
Driver |
10 Inch | 12 Inch |
|---|---|---|
FS |
36 Hz | 34 Hz |
Re |
8Ω Series | 8Ω Series |
Qms |
4.79 | 4.76 |
Qes |
.51 | .58 |
Qts |
.49 | .55 |
Mms |
139 g | 154 g |
Cms |
.131 mm/N | .145 mm/N |
Sd |
380 cm² | 530 cm² |
Vas |
27 L | 51 L |
Spl |
87.3 db 1w/1m | 89.2 db 1w/1m |
BL |
14 TM | 14 TM |
X-max |
22 mm p2p | 22 mm p2p |
Sub Diameter |
10.50" | 12.25" |
Mounting |
8.74" | 10.63" |
Depth |
4.87" | 5.50" |
Displacement |
.10 Cu. Ft. | .11 Cu. Ft. |
Power |
500 RMS | 500 RMS |
