US Acoustics "Barbara Ann" Class A/B 4 Channel Amplifier

US AcousticsIn Stock. Typically ships within 1 Business Day.

SKU: USACOU-Barbara Ann

In Stock

$399.00

US Acoustics Amplifiers bring back the Old School quality of audio with our Class(y) AB Ladies Wendy, Andrea, Lisa and Barbara Ann. Bring it on with our High Tech brawlers Mike, Nick and Big Ben creating pounding power for your subs. The technology behind US Acoustics is second to none utilizing the latest advancements in analog and "D" Class electronic design and components. US Acoustics engineers take great pride in delivering the highest quality of sound and peak performance, never sacrificing quality over cost.

From the one of the original engineers of the USA series, comes the all new US Acoustics amplifiers.

Features

4 x 100 Watts RMS @ 4 Ohm
Angled Terminals for show quality installations
Old School Full Complimentary low distortion Class AB design
Butterworth Crossover Filters for serious
high-end performance
Docking Pads® to reduce vibration and
extend the life of your amplifier
DC, Short Circuit, Thermal and
Overload Protection
Diagnostic LEDs

OUTPUT POWER @ 14.4V input
RMS per channel at 4 Ohms	100 W x 4 CH
RMS per channel at 2 Ohms	175 W x 4 CH
RMS Bridged Mono at 4 Ohms	350 W x 2 CH
RMS Mono at 1 Ohm	N/A
INPUT SENSITIVITY	200mV - 6.0V
FREQUENCY RESPONSE	10Hz - 30KHz +/- 0.5dB
THD	LESS THAN 0.01%
S/N RATIO	> 97 dB
CHANNEL SEPARATION	> 92 dB

DAMPING FACTOR @100Hz 4 ohm	> 200
CROSSOVER RANGE	CH 3&4, CH 1&2
High Pass, 12dB/Octave	15-500 Hz, 50-3K Hz
Low Pass, 24dB/Octave	55-3.5K Hz
Subsonic	N/A
Variable Bass Boost (0 to +12 dB bass boost at 45 Hz)	Selectable 0/6/12 dB
Wired remote bass control included	No
Phase Shift (0 - 180 degrees)	No
Fusing	3 x 35A
Size (L x W x H) in	16.4 x 8.9 x 2.2

2 Year Warranty
