US Acoustics Amplifiers bring back the Old School quality of audio with our Class(y) AB Ladies Wendy, Andrea, Lisa and Barbara Ann. Bring it on with our High Tech brawlers Mike, Nick and Big Ben creating pounding power for your subs. The technology behind US Acoustics is second to none utilizing the latest advancements in analog and "D" Class electronic design and components. US Acoustics engineers take great pride in delivering the highest quality of sound and peak performance, never sacrificing quality over cost.
From the one of the original engineers of the USA series, comes the all new US Acoustics amplifiers.
OUTPUT POWER @ 14.4V input | |
RMS per channel at 4 Ohms | 375 W x 1 CH |
RMS per channel at 2 Ohms | 750 W x 1 CH |
RMS Bridged Mono at 4 Ohms | N/A |
RMS Mono at 1 Ohm | 1500 W x 1 CH |
INPUT SENSITIVITY | 200mV - 6.0V |
FREQUENCY RESPONSE | 10Hz - 150Hz +/- 0.5dB |
THD | LESS THAN 0.1% |
S/N RATIO | > 101 dB |
CHANNEL SEPARATION | N/A |
DAMPING FACTOR @100Hz 4 ohm | > 250 |
CROSSOVER RANGE | |
High Pass, 12dB/Octave | N/A |
Low Pass, 24dB/Octave | 10Hz - 150Hz |
Subsonic | 15Hz - 55Hz |
Variable Bass Boost (0 to +12 dB bass boost at 50 Hz) | Yes |
Wired remote bass control included | Yes |
Phase Shift (0 - 180 degrees) | No |
Fusing | 4 x 40A |
Size (L x W x H) in | 14.1 x 8.9 x 2.2 |
2 year warranty
